Pipe Rupture Valves
Pipe rupture valves serve as a load holding valve and at the same time as a leak-free shut-off, which prevents unwanted cylinder movements. These valves are particularly characterized by a smooth throttle response.
Applications:
Boom-stick- and bucket cylinders
Design:
flat design, stepped
hydraulic pilot operated
Qmax: 400 l/min | Pmax: 420 bar
Port sizes:
SAE 3/4", SAE 1"
Applications:
Boom,-stick,-telescpopic-, and bucket cylinders
Design:
compact - suitable for smallest intallation spaces
hydraulic pilot operated
Qmax: 600 l/min | Pmax: 420 bar
Port Sizes:
SAE 3/4", SAE 1" SAE 1 1/4"
Applications:
Boom-stick- and bucket cylinders
Design:
with regeneration circuit,Energy saving
hydraulic pilot operated
Qmax: 600 l/min | Pmax: 420 bar
Port sizes:
SAE 1/2"-, SAE 1 1/2"
Applications: Design: Qmax: 500 l/min | Pmax: 420 bar Port sizes:
Boom-stick- and bucket cylinders
electrically proportional pilotet, load compensation
SAE 1", SAE 1 1/4"
Applications: Design: Qmax: 600 l/min | Pmax: 420 bar Port sizes:
Bucket cylinders
for pipe-conncetion
hydraulic pilot operated
G3/4"
Applications: Design: Modular Design Qmax: up to 400 l/min | Pmax: 420 bar Port sizes:
Bucket cylinders
ST: SAE 1", SAE 1 1/4"
